Off-shore Skid-Mounted Nitrogen Generation Equipment

Time：2025-01-03 human browsing

Product introduction

➣Membrane Separation Nitrogen generation technology is the use of different relative permeability of different gases in the membrane, and achieve the purpose of Nitrogen and oxygen separation.

➣Compared with other generation Nitrogen method, Membrane separation Nitrogen equipment is smaller, lighter, more efficient, wide usage, more convenient operation & maintenance, above are the reason to usage in wide field.

➣Component: Air compression system, Air handing system, Membrane separation Nitrogen system, Nitrogen supercharging system, central control system, box machine auxiliary system etc.

➣Adoptthe world's most advanced PRISM membrane separation Nitrogen technology andtechnology.

➣It should be designed, manufactured andtested in strict accordance with the "offshore mobile platformconstruction and classification standards".

➣It could meet the "GB3836 explosive gas atmospheres withelectrical equipment," the explosion requirements.

➣Certified byChina Classification Society (CCS) certification of offshore oil platform forNitrogen equipment.

➣Thepaint and pipeline material are well meet theMarine platform anticorrosion requirement.

➣Slip structure design could meet the crane’sweight limited requirement on the offshore platform.
